Tire building. This tire builder starts the carcass by slipping a layer of fabric onto the tire drum. The layer is made with the seam cut on the bias so that there will be no straight-across strain on the tire seams. The layer fits tightly, and each successive layer is banded to the preceding one b
From the collection of Library of Congress. Free to download, adapt and use — no permission needed.
Credit lineTire building. This tire builder starts the carcass by slipping a layer of fabric onto the tire drum. The layer is made with the seam cut on the bias so that there will be no straight-across strain on. 1941-01-01. Palmer, Alfred T., United States. Office For Emergency Management. Farm Security Administration/Office of War Information Collection, Library of Congress. Public domain.
