Forming the bead with "saucer," this tire builder follows every curve of the tire, shaping and pressing on the new layer. This saucer is matched by another on the far side of the tire which works on the other side at the same time, assuring perfect balance of the finished tire. The saucers may be sw
From the collection of Library of Congress. Free to download, adapt and use — no permission needed.
Credit lineForming the bead with "saucer," this tire builder follows every curve of the tire, shaping and pressing on the new layer. This saucer is matched by another on the far side of the tire which works on t. 1941-01-01. Palmer, Alfred T., United States. Office For Emergency Management. Farm Security Administration/Office of War Information Collection, Library of Congress. Public domain.
