Lockheed XFV-1 model in the 40x80 foot wind tunnel at NASA Ames Research Center
Public domain

Lockheed XFV-1 model in the 40x80 foot wind tunnel at NASA Ames Research Center

NASA / ARC · 1952-05-16 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Wide shot of 40x 80 wind tunnel settling chamber with Lockheed XFV-1 model. Project engineer Mark Kelly (not shown). Remote controlled model flown in the settling chamber of the 40x80 wind tunnel. Electric motors in the model, controlled the counter-rotating propellers to test vertical takeoff. Test no.

NASA Image and Video Library’s own description
Subjects
LockheedAeronauticsWind Tunnel40x80ft.
Credit lineLockheed XFV-1 model in the 40x80 foot wind tunnel at NASA Ames Research Center. NASA/ARC, 1952-05-16. Public domain. ID: A-17168.
