40X80 foot Wind Tunnel Tests Of Avrocar Annular Jet VTOL Airplane.
Public domain

40X80 foot Wind Tunnel Tests Of Avrocar Annular Jet VTOL Airplane.

NASA / ARC · 1961-04-20 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

3/4 front view of Avrocar without tail, showing ground board and variable height struts. The ground board minimizes the boundary layer on the floor under the model. black and white negative: KODAK T-MAX 100 Professional.

NASA Image and Video Library’s own description
Subjects
AeronauticsAmes40x80ft.AvrocarVTOLWind Tunnel
Credit line40X80 foot Wind Tunnel Tests Of Avrocar Annular Jet VTOL Airplane.. NASA/ARC, 1961-04-20. Public domain. ID: A-27770.
