General Electric Fan-In-Fuselage Lifting Model in the 40x80 Foot Wind Tunnel at NASA Ames.
Public domain

General Electric Fan-In-Fuselage Lifting Model in the 40x80 Foot Wind Tunnel at NASA Ames.

NASA / ARC · 1961-05-15 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

G.E. Fan-in-fuselage model (lifting). 3/4 rear view of fan at low G.P. position. Lift fan on variable height strut for ground effects studies with reaction control. T-Tail.

NASA Image and Video Library’s own description
Subjects
Fan-In-FuselageG.E.AmesARCAeronautics40x80ftWind Tunnel
Credit lineGeneral Electric Fan-In-Fuselage Lifting Model in the 40x80 Foot Wind Tunnel at NASA Ames.. NASA/ARC, 1961-05-15. Public domain. ID: A-27828.
