Bell Full-Scale X-22A Ducted Fan with Semi-Span Mount in Ames 40x80ft Wind Tunnel.
Public domain

Bell Full-Scale X-22A Ducted Fan with Semi-Span Mount in Ames 40x80ft Wind Tunnel.

NASA / ARC · 1999-03-17 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Bell X-22A full scale, Model-C ducted fan with semi-span mount. Duct at 90 degrees with Chuck Greco.

NASA Image and Video Library’s own description
Subjects
BellDuctedFanAmesARC40x80ftWind TunnelAeronautics
Credit lineBell Full-Scale X-22A Ducted Fan with Semi-Span Mount in Ames 40x80ft Wind Tunnel.. NASA/ARC, 1999-03-17. Public domain. ID: A-32844.
