Rotating Cylinder Applied To Flaps In 40X80 Foot Wind Tunnel.
Public domain

Rotating Cylinder Applied To Flaps In 40X80 Foot Wind Tunnel.

NASA / ARC · 1967-06-23 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

4 propeller model with rotating cylinder flap. Propellers running. 3/4 front view. DAVE JONES (PROPS TURNING)

NASA Image and Video Library’s own description
Subjects
AeronauticsARCAmes40x80ftWind Tunnel
Credit lineRotating Cylinder Applied To Flaps In 40X80 Foot Wind Tunnel.. NASA/ARC, 1967-06-23. Public domain. ID: A-39267.
