Swept Augmentor Wing Model Installed in the Ames 40X80 Foot Wind Tunnel.
Public domain

Swept Augmentor Wing Model Installed in the Ames 40X80 Foot Wind Tunnel.

NASA / ARC · 1998-10-27 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

(11/12/1971) 3/4 rear view of swept 75% scale augmentor wing quest model being installed into the test section of the Ames 40x80 foot wind tunnel, overhead doors open.

NASA Image and Video Library’s own description
Subjects
AmesArcAeronautics40x80ftWind Tunnelaugmentor
Credit lineSwept Augmentor Wing Model Installed in the Ames 40X80 Foot Wind Tunnel.. NASA/ARC, 1998-10-27. Public domain. ID: A71-8291.
