General Aerodynamic Characteristics of a Research Model with High Disk Loading Direct Lifting Fan Mounted in Fuselage
Public domain

General Aerodynamic Characteristics of a Research Model with High Disk Loading Direct Lifting Fan Mounted in Fuselage

NASA / ARC · 1960-10-26 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

3/4 Low front view of fuselage and fan. Showing jet engine hanging below. Lift fan powered by jet exhaust.

NASA Image and Video Library’s own description
Subjects
ARCAmes40x80ftWind TunnelAernautics
Credit lineGeneral Aerodynamic Characteristics of a Research Model with High Disk Loading Direct Lifting Fan Mounted in Fuselage. NASA/ARC, 1960-10-26. Public domain. ID: AC-27149-B.
