F-5D Airplane modified to "ogee" platform inlet plug installed in Ames 40x80 foot wind tunnel.
Public domain

F-5D Airplane modified to "ogee" platform inlet plug installed in Ames 40x80 foot wind tunnel.

NASA / ARC · 1963-09-06 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

3/4 front view of Douglas F5D Skylancer modified to "ogee" platform inlet plug installed in Ames 40x80 foot wind tunnel.

NASA Image and Video Library’s own description
Subjects
AmesARCAeronautics40x80ftWind TunnelDouglasF5DSkylancer
Credit lineF-5D Airplane modified to "ogee" platform inlet plug installed in Ames 40x80 foot wind tunnel.. NASA/ARC, 1963-09-06. Public domain. ID: AC-31304.
