AirBOS4
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
Composite image of Background Oriented Schlieren (BOS) data (contour) with a cut-out images of the T-38’s during a Mach Number 1.01 pass. This data is the first time shockwave interactions between two full scale aircraft traveling faster than the speed of sound have been imaged and shown with schlieren visualization. Original recording of the pass taken in the Black Mountain Supersonic Corridor at near Edwards AFB in December of 2018.
NASA Image and Video Library’s own descriptionCredit lineAirBOS4. NASA/ARC, 2018-12-11. Public domain. ID: ACD21-0016-001_F3_P3_Knife_red_planedrop_12Hprint.
