NASA Armstrong Builds Model Wing

NASA / AFRC · 2023-09-27 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

A jury strut adaptor is created for a 10-foot model of the Transonic Truss-Braced Wing at NASA’s Armstrong Flight Research Center, in Edwards, California. The aircraft concept involves a wing braced on an aircraft using diagonal struts that also add lift and could result in significantly improved aerodynamics.

NASA Image and Video Library’s own description
Subjects
NASA ArmstrongAFRCFlight InnovationFlightTransonic Truss-Braced WingTTBWSustainable Flight DemonstratorAdvanced Air Transport TechnologyEdwards Air Force BaseCalifornia
Credit lineNASA Armstrong Builds Model Wing. NASA/AFRC, 2023-09-27. Public domain. ID: AFRC2023-0157-020.
