ARC-1964-AC-32745

NASA / ARC · 1964-09-19 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

XV-5A airplane installed in 40x80ft Subsonic Wind Tunnel at NASA Ames Research Center with Tom Mills. The propulsive lift system was tested to determine power-on performance characteristics in preparation for flight tests. Used in Memoiors of an Aeronautical Engineer, Flight Tests at Ames Research Center 1940-1970 NASA-SP-2002-4526 (Seth B. Anderson)

NASA Image and Video Library’s own description
Subjects
XV-5A40x80ft
Credit lineARC-1964-AC-32745. NASA/ARC, 1964-09-19. Public domain. ID: ARC-1964-AC-32745.
