M2-F1 cockpit

NASA / AFRC · 1963-03-21 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

This photo shows the cockpit configuration of the M2-F1 wingless lifting body. With a top speed of about 120 knots, the M2-F1 had a simple instrument panel. Besides the panel itself, the ribs of the wooden shell (left) and the control stick (center) are also visible.

NASA Image and Video Library’s own description

Subjects

M2-F1 Pontiac Catalina convertible Space Shuttle Alfred J. Eggers Ames Aeronautical Laboratory Ames Research Center NASA Flight Research Center Dryden Flight Research Center Rogers Dry Lakebed

Credit lineM2-F1 cockpit. NASA/AFRC, 1963-03-21. Public domain. ID: E-9649.
