F-111B Wings Swept
Public domain

F-111B Wings Swept

NASA / AFRC · 1972-11-15 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

The F-111B with its wings swept to their maximum angle. It carried the Mission Adaptive Wing, a single-piece composite structure with leading and trailing edges that could be lowered or raised in flight.

NASA Image and Video Library’s own description
Subjects
AFRCArmstrong Flight Research CenterNACANational Advisory CommitteeDFRCDryden Flight Research CenterF-111BMission Adaptive WingSwept
Credit lineF-111B Wings Swept. NASA/AFRC, 1972-11-15. Public domain. ID: EC72-3374.
