About this work
This photograph shows a modified General Dynamics AFTI/F-111A Aardvark with supercritical mission adaptive wings (MAW) installed. The four dark bands on the right wing are the locations of pressure orifices used to measure surface pressures and shock locations on the MAW. The El Paso Mountains and Red Rock Canyon State Park Califonia, about 30 miles northwest of Edwards Air Force Base, are seen directly in the background.
NASA Image and Video Library’s own descriptionSubjects
Credit lineEC85-33205-07. NASA/AFRC, 1985-10-18. Public domain. ID: EC85-33205-07.
