F-15B in flight with X-33 Thermal Protection Systems (TPS) on Flight Test Fixture
Public domain

F-15B in flight with X-33 Thermal Protection Systems (TPS) on Flight Test Fixture

NASA / AFRC · 1998-05-14 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

In-flight photo of the NASA F-15B used in tests of the X-33 Thermal Protection System (TPS) materials. Flying at subsonic speeds, the F-15B tests measured the air loads on the proposed X-33 protective materials. In contrast, shock loads testing investigated the local impact of the supersonic shock wave itself on the TPS materials. Similar tests had been done in 1985 for the space shuttle tiles, using an F-104 aircraft.

NASA Image and Video Library’s own description
Subjects
F-15B Images
Credit lineF-15B in flight with X-33 Thermal Protection Systems (TPS) on Flight Test Fixture. NASA/AFRC, 1998-05-14. Public domain. ID: EC98-44554-31.
