NASA F-15B #836 in flight with Quiet Spike attached
Public domain

NASA F-15B #836 in flight with Quiet Spike attached

NASA / AFRC · 2006-09-27 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

NASA F-15B #836 in flight with Quiet Spike attached. The project seeks to verify the structural integrity of the multi-segmented, articulating spike attachment designed to reduce and control a sonic boom.

NASA Image and Video Library’s own description
Subjects
F-15F-15B836testbedGulfstreamQuiet Spikesonic boom mitigatorcompositearticulatingFlight #298Craig Bomben pilotMike Thomson backseat
Credit lineNASA F-15B #836 in flight with Quiet Spike attached. NASA/AFRC, 2006-09-27. Public domain. ID: ED06-0184-13.
