Turning Vanes inside the Altitude Wind Tunnel
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
Men stand in front of turning vanes inside the Altitude Wind Tunnel (AWT) at the National Advisory Committee for Aeronautics (NACA) Aircraft Engine Research Laboratory. The AWT was the only wind tunnel capable of testing full-size aircraft engines in simulated altitude conditions. A large wooden drive fan, located on the other side of these vanes, created wind speeds up to 500 miles per hour. The drive shaft connected the fan to the induction motor located in an adjacent building.
NASA Image and Video Library’s own descriptionCredit lineTurning Vanes inside the Altitude Wind Tunnel. NASA/GRC, 1944-02-23. Public domain. ID: GRC-1944-C-03991.
