16-Inch Diameter Ramjet Prepared for Flight Test
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
A NACA researcher prepares a 16-inch diameter and 16-foot long ramjet for a launch over Wallops Island in July 1947. The Lewis Flight Propulsion Laboratory conducted a wide variety of studies on ramjets in the 1940s and 1960s to determine the basic operational data necessary to design missiles. Although wind tunnel and test stand investigations were important first steps in determining these factors, actual flight tests were required.
NASA Image and Video Library’s own descriptionCredit line16-Inch Diameter Ramjet Prepared for Flight Test. NASA/GRC, 1947-07-23. Public domain. ID: GRC-1947-C-19067.
