Brayton Cycle Power System in the Space Power Facility
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
Set up of a Brayton Cycle Power System test in the Space Power Facility’s massive vacuum chamber at the National Aeronautics and Space Administration’s (NASA) Plum Brook Station in Sandusky, Ohio. The $28.4-million facility, which began operations in 1969, is the largest high vacuum chamber ever built. The chamber is 100 feet in diameter and 120 feet high. It can produce a vacuum deep enough to simulate the conditions at 300 miles altitude.
NASA Image and Video Library’s own descriptionCredit lineBrayton Cycle Power System in the Space Power Facility. NASA/GRC, 1969-07-23. Public domain. ID: GRC-1969-C-02599.
