CAPE CANAVERAL, Fla. – The last newly manufactured section of the Ares I-X test rocket, the frustum, is offloaded in the Assembly and Refurbishment Facility of NASA's Kennedy Space Center. Resembling a giant funnel, the frustum's function is to transition the primary flight loads from the rocket's upper stage to the first stage. The frustum is located between the forward skirt extension and the upper stage of the Ares I-X.
NASA Image and Video Library’s own descriptionSubjects
Credit lineKSC-2009-1747. NASA/KSC, 2009-02-20. Public domain. ID: KSC-2009-1747.
