KSC-2009-2494

NASA / KSC · 2009-04-02 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

CAPE CANAVERAL, Fla. – In the Rotation, Processing and Surge Facility at NASA's Kennedy Space Center in Florida, cranes attached to the Ares I-X center forward segment lift it off the transporter to raise it to vertical. Once vertical, the segment will be moved to a stand. The booster used for the Ares I-X launch is being modified by adding new forward structures and a fifth segment simulator. The stacking operations are scheduled to begin in the Vehicle Assembly Building in April.

NASA Image and Video Library’s own description
Subjects
I-X, forward segment, RPSF
Credit lineKSC-2009-2494. NASA/KSC, 2009-04-02. Public domain. ID: KSC-2009-2494.
