Orion EFT-1 Heat Shield Offload from Truck onto Foam Pads (Dunna
Public domain

Orion EFT-1 Heat Shield Offload from Truck onto Foam Pads (Dunna

NASA / KSC · 2017-04-27 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Inside High Bay 2 in the Vehicle Assembly Building (VAB) at NASA's Kennedy Space Center in Florida, the Orion heat shield from Exploration Flight Test-1 is secured on foam blocks. The heat shield is being transferred from the Orion Program to the Ground Systems Development and Operations Program, Landing and Recovery Operations. In the VAB, the heat shield will be integrated with the Orion ground test article and used for future underway recovery testing.

NASA Image and Video Library’s own description
Subjects
GSDOOrionEFT-1 heat shieldVABexplorationJourney to Mars
Credit lineOrion EFT-1 Heat Shield Offload from Truck onto Foam Pads (Dunna. NASA/KSC, 2017-04-27. Public domain. ID: KSC-20170427-PH_SWW01_0072.
