Guppy Fit Check for Orion EM-1

NASA / KSC · 2019-03-13 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

A fit check of the Orion Crew and Service Module Horizontal Transporter (CHT) with NASA's Super Guppy aircraft began March 12, 2019, at NASA Kennedy Space Center’s Shuttle Landing Facility in Florida, operated by Space Florida. In this photo, the U.S. Air Force aircraft loader with the CHT is moved toward the Super Guppy. The fit check is being performed to confirm loading operations, ensure that the CHT fits inside the Super Guppy and test the electrical interface to aircraft power.

NASA Image and Video Library’s own description
Subjects
OrionExploration Mission-1EM-1thermal testingcrew moduleservice moduleEurope service modulemoon to marsSuper Guppyfit checkShuttle Landing FacilitySLF
Credit lineGuppy Fit Check for Orion EM-1. NASA/KSC, 2019-03-13. Public domain. ID: KSC-20190312-PH_KLS02_0049.
