13.1 Foot Diameter Fluted-Core Sandwich Composite Test Article
Public domain

13.1 Foot Diameter Fluted-Core Sandwich Composite Test Article

NASA / LRC · 2013-09-25 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

White light shape and measurement of a 13.1 Foot diameter fluted-core sandwich composite test article designed by LaRC and fabricated by Boeing Under Space Act Agreement SAA1-737, Annex 14. to be tested in LaRC's combined Loads Testing System (COLTS).

NASA Image and Video Library’s own description
Subjects
BucklingCompositeFluted coreCyling
Credit line13.1 Foot Diameter Fluted-Core Sandwich Composite Test Article. NASA/LRC, 2013-09-25. Public domain. ID: LRC-2013-00753.
