Nine-Paneled Mirror for ASTHROS
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
The mirror on NASA's Astrophysics Stratospheric Telescope for High Spectral Resolution Observations at Submillimeter-wavelengths mission, or ASTHROS, is composed of nine panels, coated in nickel and gold. Here, engineers attach panels to the mirror's support structure. The panels must be aligned to within 0.0001 inches (2.5 micrometers), or a fraction of the width of a human hair. Manufacturing multiple panels requires less time and expense than making the mirror as a single piece.
NASA Image and Video Library’s own descriptionSubjects
Credit lineNine-Paneled Mirror for ASTHROS. NASA/JPL, 2022-06-29. Public domain. ID: PIA25167.
