TMS installation at A-1 Test Stand
From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.
About this work
A new thrust measurement system is lifted onto the A-1 Test Stand deck at NASA's John C. Stennis Space Center in preparation for its installation. The new system is a state-of-the-art upgrade for the testing structure, which is being prepared for testing of next-generation rocket engines. The system was fabricated by Thrust Measurement Systems in Illinois at a cost of about $3.5 million.
NASA Image and Video Library’s own descriptionCredit lineTMS installation at A-1 Test Stand. NASA/SSC, 2010-03-03. Public domain. ID: SSC-20100303-S00308.
