About this work

Notice anything different about the wings on this airliner? This conceptual truss-braced wing narrowbody is an aircraft with a 170ft span folding wing. By utilizing trusses, the aircraft can have longer, thinner wings with greater aspect ratios. This, in turn, translates into less drag and 5-10% less fuel burned.

NASA Image and Video Library’s own description
Subjects
TTBWtransonic truss-braced wingtruss-bracedtruss-braced wingwingnarrowbodysustainablesustainabilitysustainable aviationAeronauticsaircraftairplane
Credit lineTTBW-90-lt-blue-windows-left-top-bank. NASA/HQ, 2020-12-09. Public domain. ID: TTBW-90-lt-blue-windows-left-top-bank.
