Mapping Sequence performed during the STS-131 R-Bar Pitch Maneuver
Public domain

Mapping Sequence performed during the STS-131 R-Bar Pitch Maneuver

NASA / JSC · 2010-04-07 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

ISS023-E-020003 (7 April 2010) --- This view of the aft portion of the space shuttle Discovery, including the three main engines and part of the cargo bay, was provided by an Expedition 23 crew member during a survey of the approaching vehicle prior to docking with the International Space Station. As part of the survey and part of every mission's activities, the STS-131 Discovery crew performed a back-flip for the rendezvous pitch maneuver (RPM).

NASA Image and Video Library’s own description
Credit lineMapping Sequence performed during the STS-131 R-Bar Pitch Maneuver. NASA/JSC, 2010-04-07. Public domain. ID: iss023e020003.
