CEV Seat Layout Evaluation
Public domain

CEV Seat Layout Evaluation

NASA / JSC · 2007-11-15 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Photographic documentation of the CEV Seat Layout Evaluation taken in the Orion mockup located in bldg 9NW, Johnson Space Center (JSC). Test subjects in orange Launch and Entry Suit (LES) is visible in the seat.

NASA Image and Video Library’s own description
Credit lineCEV Seat Layout Evaluation. NASA/JSC, 2007-11-15. Public domain. ID: jsc2007e102463.
