Venturi Tube

Pioneer Instrument Co. · ca. 1920 · Copper Alloy, Paint, Wax Pencil

From the collection of National Air and Space Museum. Free to download, adapt and use — no permission needed.

About this work

162mm long, 30mm diameter mouth; experimental.

National Air and Space Museum’s own description
Subjects
Flight instruments
Credit lineVenturi Tube. ca. 1920. Pioneer Instrument Co.. National Air and Space Museum, Transferred from the Department of Commerce. CC0.
