Rolls-Royce Merlin R.M. 14S.M. Mk 100 V-12 Engine

Rolls-Royce Ltd. (Derby, U.K.) · 1944 · Aluminum and Steel

From the collection of National Air and Space Museum. Free to download, adapt and use — no permission needed.

About this work

Type: Reciprocating, V-type, 12 cylinders, pressure liquid cooled, supercharged

National Air and Space Museum’s own description
Subjects
Rotary enginesReciprocating (piston) enginesPropulsion systems
Credit lineRolls-Royce Merlin R.M. 14S.M. Mk 100 V-12 Engine. 1944. Rolls-Royce Ltd. (Derby, U.K.). National Air and Space Museum, Transferred from the United States Air Force, Park Ridge Facility. CC0.
