Maybach MB IVa, In-line 6 Engine
CC0 · no rights reserved

Maybach MB IVa, In-line 6 Engine

Maybach Motorenbau G.m.b.H. (Friedrichshafen a/Bodensee, Germany) · Circa 1916 · Steel, Aluminum, Paint, Copper, Rubber, Wood, Ceramic, Adhesive, Textile

From the collection of National Air and Space Museum. Free to download, adapt and use — no permission needed.

About this work

Type: Reciprocating, 6 cylinders, in-line, air cooled

National Air and Space Museum’s own description
Subjects
Rotary enginesReciprocating (piston) enginesPropulsion systems
Credit lineMaybach MB IVa, In-line 6 Engine. Circa 1916. Maybach Motorenbau G.m.b.H. (Friedrichshafen a/Bodensee, Germany). National Air and Space Museum, Transferred from the U.S. Navy. CC0.
