Surveyor's Chain Winder
From the collection of National Museum of American History. Free to download, adapt and use — no permission needed.
About this work
Surveyor's chain winder consisting of a cylindrical central shaft running through an X-shaped frame with incurved or U-shaped sides forge-welded to the top and bottom crosspieces. Shaft is secured at top with a square washer and ends at bottom in a spear point that can be driven into the ground. One end of top crosspiece has an iron baluster handle; opposite end of bottom crosspiece has a small spike that can also be pushed into the ground to prevent reel from moving. No marks.
National Museum of American History’s own descriptionSubjects
Credit lineSurveyor's Chain Winder. 1760-1840. National Museum of American History, Gift of Dr. and Mrs. Arthur M. Greenwood. CC0.
