Page reciprocating motor, patent #10480
From the collection of National Museum of American History. Free to download, adapt and use — no permission needed.
About this work
Patent model of Charles Page's 1853 electro-locomotive. US Patent 10480, Electromagnetic Engine, issued 31 January 1854 to Charles G. Page. No extant maker's markings. Four solenoids of heavy wires are set horizontally, with a sliding framework carrying the armature to and fro from the coils. A lever mechanism operates a small flywheel. Double-axis reciprocating engine. Patent Claims: The use of horizontal "axial" bars in combination with electromagnets and armatures, and the use of square wires in construction of helices. Reference: W. James King, Development of Electrical Technology in the 19th Century, page 270.
National Museum of American History’s own descriptionSubjects
Credit linePage reciprocating motor, patent #10480. 1853. Page, Charles Grafton. National Museum of American History. CC0.
