Patend model for an inking apparatus for printing presses

Hubbard, James F. · ca 1875 · wood (overall material)

From the collection of National Museum of American History. Free to download, adapt and use — no permission needed.

About this work

This patent model demonstrates inventions relating to the inking apparatus on oscillating presses, such as Potter's jobbing press. The two patents, numbered 169191 for bearings for distributing rollers, and 171243 for the inking apparatus itself, are demonstrated on one model.

National Museum of American History’s own description

Subjects

Patents apparatus, inking Models Work and Industry: Graphic Arts

Credit linePatend model for an inking apparatus for printing presses. ca 1875. Hubbard, James F.. National Museum of American History. CC0.
