Multiple Hydrostatic Lubricator Model
CC0 · no rights reserved

Multiple Hydrostatic Lubricator Model

Gates, John · 1873 · brass (overall material)

From the collection of National Museum of American History. Free to download, adapt and use — no permission needed.

About this work

This is an automatic lubricator that delivers lubricating oil into the steam being supplied to a steam engine at any desired rate. It employs the pressure due to a column of water plus the pressure of the steam in the main to force the oil into the main against the steam pressure.
