Model of a Paddle Wheel
From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.
About this work
Model of a paddle wheel (port side) with eight moving boards. The axle runs through to the outside of the wheel; the boards, each provided with their own axle, derive their movement via spokes from an eccentric around the axle against the ship's side. The model is moved with a crank. Scale 1:10 (derived).
Rijksmuseum, Amsterdam’s own descriptionSubjects
Credit lineModel of a Paddle Wheel. 1835. D. van den Bosch. Rijksmuseum, Amsterdam. Public domain.
