Floor plan of the fourth floor of a dwelling house
Public domain

Floor plan of the fourth floor of a dwelling house

Willem Springer jr. · c. 1864 · pen; tracing paper; paper; ink

From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.

About this work

Page 161 from a sketchbook of 164 pages.

Rijksmuseum, Amsterdam’s own description
Subjects
schetsboekbladplan ~ architecture
Credit linePlattegrond van de vierde verdieping van een woonhuis. c. 1864. Willem Springer jr.. Rijksmuseum, Amsterdam. Public domain.
