A-28399. GE Fan in Wing in Ames 40x80 foot wind tunnel.
Public domain

A-28399. GE Fan in Wing in Ames 40x80 foot wind tunnel.

NASA / ARC · 1961-10-24 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Top view if GE fan model, 3/4 top view. Straight wing. 1 fan per wing, conventional struts. Woody Kook, Branch Chief.

NASA Image and Video Library’s own description
Subjects
General ElectricGEFan in wing40x80ftWind TunnelAmesARCAeronautics
Credit lineA-28399. GE Fan in Wing in Ames 40x80 foot wind tunnel.. NASA/ARC, 1961-10-24. Public domain. ID: A-28399.
