Lift Fan Model In Ames 40 X 80 Wind Tunnel.
Public domain

Lift Fan Model In Ames 40 X 80 Wind Tunnel.

NASA / ARC · 1969-09-08 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

Forward overhead view of lift fan transport model, with two, of a possible six, high pressure ratio wing lift fans.

NASA Image and Video Library’s own description
Subjects
Lift FanARCAmes40x80ftWind Tunnel
Credit lineLift Fan Model In Ames 40 X 80 Wind Tunnel.. NASA/ARC, 1969-09-08. Public domain. ID: A-42536-003.
