Mapping sequence performed during the STS-121 R-Bar Pitch Maneuver
Public domain

Mapping sequence performed during the STS-121 R-Bar Pitch Maneuver

NASA / JSC · 2006-07-06 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

ISS013-E-47629 (6 July 2006) --- A close-up view of Space Shuttle Discovery's tail section is featured in this image photographed by an Expedition 13 crewmember on the International Space Station during STS-121 R-Pitch Maneuver survey on Flight Day 3. Visible are the shuttle's main engines, vertical stabilizer, orbital maneuvering system (OMS) pods, reaction control system (RCS) jets and a portion of payload bay door radiator and wings.

NASA Image and Video Library’s own description
Credit lineMapping sequence performed during the STS-121 R-Bar Pitch Maneuver. NASA/JSC, 2006-07-06. Public domain. ID: iss013e47629.
