Mapping Sequence performed during the STS-131 R-Bar Pitch Maneuver
Public domain

Mapping Sequence performed during the STS-131 R-Bar Pitch Maneuver

NASA / JSC · 2010-04-07 · photograph (digital archive)

From the collection of NASA Image and Video Library. Free to download, adapt and use — no permission needed.

About this work

ISS023-E-020004 (7 April 2010) --- This view of the aft portion of the space shuttle Discovery, including the three main engines and part of the wings, was provided by an Expedition 23 crew member during a survey of the approaching vehicle prior to docking with the International Space Station. As part of the survey and part of every mission's activities, the STS-131 Discovery crew performed a back-flip for the rendezvous pitch maneuver (RPM).

NASA Image and Video Library’s own description
Credit lineMapping Sequence performed during the STS-131 R-Bar Pitch Maneuver. NASA/JSC, 2010-04-07. Public domain. ID: iss023e020004.
