Model of a Hydraulic Press
Public domain

Model of a Hydraulic Press

Joseph Bramah · 1820 · iron (metal); copper (metal); wood (plant material)

From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.

About this work

Model of a simple hydraulic press on a wooden baseboard. On one side stands a hand-operated pump, equipped with a pump arm, regulator, overflow and safety valve. The pump arm can be set in two positions. The regulator is a screw valve. The safety valve is adjusted with a weight. A pipe for the fluid runs from the pump to the bottom of the press, where an oval press platform is pushed upwards.

Rijksmuseum, Amsterdam’s own description
Subjects
demonstration model
Credit lineModel of a Hydraulic Press. 1820. Joseph Bramah. Rijksmuseum, Amsterdam. Public domain.
