Model of Steering Gear

anonymous · 1820 - 1858 · wood (plant material); brass (alloy)

From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.

About this work

Model of a steering mechanism with gearing on a baseboard. The model shows a square rudder head to which a toothed quadrant is attached; a gear on a shaft transfers the movement of the steering wheel to the quadrant. The steering wheel consists of four spokes.
