Model of Steering Gear
From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.
About this work
Table model showing a section of a deck with a steering mechanism, incomplete. The square rudder head has a steering quadrant, the teeth of which engage with a transverse endless screw; gears transfer the movement of the steering wheel to this endless screw. Below the endless screw is a dial of an axiometer, the gearing of which is missing.
Rijksmuseum, Amsterdam’s own descriptionSubjects
Credit lineModel of Steering Gear. c. 1817. Rijkswerf Rotterdam. Rijksmuseum, Amsterdam. Public domain.
