Elliptic Trammel

This wooden model is a prime example of an elliptic trammel, often referred to as the Trammel of Archimedes. An oval shape, the ellipse is one of the four conic sections, the others being the circle, the parabola, and the hyperbola. Ellipses are important curves used in the mathematical sciences. For example, the planets follow elliptical orbits around the sun. Ellipses are required in surveying, engineering, architectural, and machine drawings for two main reasons. First, any circle viewed at an angle will appear to be an ellipse. Second, ellipses were common architectural elements, often used in ceilings, staircases, and windows, and needed to be rendered accurately in drawings. Several types of drawing devices that produce ellipses, called ellipsographs or elliptographs, were developed and patented in the late 19th and early 20th centuries.
