Model of a Section of an Armoured Turret
From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.
About this work
Model of a part of a hemispherical gun turret, on a baseboard. The outer shell consists of three of the total twenty-six segments; the inner shell is built up of horizontal plates. At three-quarters height, a firing port is provided, and the inner shell is thickened at that point. The outer segments do not meet at the top, leaving a circular opening. Scale 1:5 (derived).
Rijksmuseum, Amsterdam’s own descriptionSubjects
Credit lineModel of a Section of an Armoured Turret. 1862. Rijkswerf Vlissingen. Rijksmuseum, Amsterdam. Public domain.
