Model of a Rudder Head for a 44-Gun Frigate
Public domain

Model of a Rudder Head for a 44-Gun Frigate

c. 1820 - c. 1858 · wood (plant material); brass (alloy)

From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.

About this work

Model of a square rudder head with two brass rudder posts. The lower, long rudder post is secured with a long stay and two turnbuckles. The upper, short rudder post is set in a small brass rudder head mounted on the wooden head. Both rudder posts have two eyes. Scale 1:10.

Rijksmuseum, Amsterdam’s own description
Subjects
demonstration model
Credit lineModel of a Rudder Head for a 44-Gun Frigate. c. 1820 - c. 1858. Rijksmuseum, Amsterdam. Public domain.
